• FRAMESET

  1. FRAME

     Arcadex Carbon, 1.5″ headset, seatpost diam. 31.6mm, thru axle 12x142mm, flat mount caliper, Pressfit 41 BB, compatible with 42mm tire and mudguard predisposition, sizes: XS-SM-MD-LG-XL

  2. FORK

     Bianchi Full Carbon Disc, 1.5″ head, flat mount caliper, thru axle 12x100mm

  3. HEADSET

     FSA SMR HS with 1.1/8” custom top cone Bianchi, H2475, Internal Headset, Integrated Alloy custom top cup 1.1/8″, 1.5″, 36°/45° ACB

• DRIVETRAIN

  1. SHIFTERS

     Shimano GRX 600 ST-RX600 1x11sp

  2. REAR DERAILLEUR

     Shimano GRX RD-RX812 11sp

  3. CRANKSET

     Shimano GRX 600 FC-RX600 40T, Crank Length: 170mm-XS-SM, 172.5mm-MD-LG, 175mm-XL

  4. BOTTOM BRACKET

     Shimano BB-RS500-PB, press fit

  5. CHAIN

     Kmc X11-1 EPT finish

• BRAKES

  1. BRAKES

     Shimano BR-RX400

  2. BRAKELEVERS

     included w/shifters

  3. ROTOR

     Shimano SM-RT70, diam. 160mm

• WHEELS

  1. WHEELS

     AlexRims GD24 disc 622-21, tubeless ready

  2. REARHUB

     Shimano FH-RS470

  3. FRONTHUB

     Shimano HB-RS470

  4. TIRE

     WTB Riddler Comp 700×37

• COCKPIT

  1. STEM

     Reparto Corse by Fsa ST-OS-188/SMR-0°, Alloy 6061 , 1 1/4″, rise 0°, Ext: 80mm-XS/S, 100mm-M, 120mm-L/XL

  2. HANDLEBAR

     Reparto Corse Aluminum 6061, reach 70mm, flare angle 16°, drop cc 120 x size 40cm and 130mm, size: 40cm-XS/S, 42cm-M/L, 44cm-XL

  3. GRIPS

     La Spirale Ribbon cork

• SADDLE

  1. SEATPOST

     Reparto Corse Alloy shaft AL6061, alloy head, 15mm offset, 31,6mm, Length: 300mm-XS, 350mm-S/M/L/XL

  2. SADDLE

     Reparto Corse 2315HRN, rail steel black, open, cover PU, lenght/wide 250x148mm

Based on component availability, Bianchi reserves the right to make changes on specifications without notice.

GEOMETRY

Arcadex
SIZE	A	B1	C	D	E	F	G	G1	H	I	X	Y	WB
XS	440	522	425	75	120	596	74.5°	70.5°	50	416	365	565	1010
SM	480	535	425	75	135	605	74°	70.5°	50	416	369	579	1018
MD	520	550	425	75	150	610	73.5°	71°	50	416	374	595	1024
LG	550	565	425	75	165	626	73.5°	71°	50	416	384	609	1039
XL	580	585	425	75	180	640	73°	71°	50	416	394	623	1054
